6
Technical data
Rated voltage
Type of guide bar (pre-fitted)
Type of saw chain (pre-fitted)
Max. cutting speed
Max. cutting length
Chain pitch
Driving link thickness
Chain wheel tooth pitch
Weight (without set of blade and
saw chain)
Weight (with battery)
Subject to technical changes!
Noise and vibration
WARNING
Noise can have serious effects on your health. If the
machine noise exceeds 85 dB, please wear suitable
hearing protection for you and persons in the vicinity.
The noise and vibration values have been determined in
accordance with EN 62841-1.
Noise data
Sound pressure L
pA
Measurement uncertainty K
Sound power L
wA
Measurement uncertainty K
Vibration parameters
Vibration a
h
Measurement uncertainty K
The total vibration emission values specified and the de-
vice emissions values specified have been measured in
accordance with a standardised test procedure and can
be used for comparison of one electric tool with another.
The total noise emission values specified and the total vi-
bration emission values specified can also be used for an
initial estimation of the load.
WARNING
The noise emission values and vibration emis-
sion value can vary from the specified values
during the actual use of the power tool, de-
pending on the type and the manner in which
the electric tool is used, and in particular the
type of workpiece being processed.
Try to keep the stress as low as possible. For example:
Limit working time. In doing so, all parts of the operating
cycle must be taken into account (such as times in
which the power tool is switched off or times in which it
is switched on, but is not running under a load).
24 | GB
20 V
JHC 5"
CB05-28-43P
JHC
030,043.28
4.8 m/s
127 mm
0.30"
0.043"/1.09
7T / 7.62 mm
(0.3")
1.2 kg
1.79 kg
82.5 dB
3 dB
pA
90.5 dB
2 dB
wA
<2.5 m/s
1.5 m/s
www.scheppach.com
7
Unpacking
WARNING
The product and the packaging material are not
children's toys!
Do not let children play with plastic bags, films or
small parts! There is a danger of choking or suffo-
cating!
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
mm
• Check the product and accessory parts for transport
damage. Immediately report any damage to the trans-
port company that delivered the Product. Later claims
will not be recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
8
Before commissioning
DANGER
Danger of injury!
If an incompletely assembled product is used, serious
injuries can be caused.
–
Do not use the product until it has been fully fitted.
–
Before each use, carry out a visual inspection to
check that the product is complete and does not
contain any damaged or worn components. Safety
and protective devices must be intact.
2
WARNING
2
Danger of injury!
Remove the battery from the power tool before carrying
out any work on the power tool (e.g. maintenance, tool
change, etc.) and when transporting and storing it.
There is a risk of injury if the on/off switch is operated
unintentionally.
WARNING
Danger of injury when handling the saw
chain or the blade!
–
Wear cut-resistant gloves.
Note:
• The chainsaw guide bar and the chain are already
pre-fitted for packaging and transport reasons.
• A new saw chain stretches and needs to be re-ten-
sioned more often. Check and adjust the chain ten-
sion regularly after each cut.
• Only use saw chains and blades designed for this
product.
