Attention: Danger of accidents!
The wood must always rest on both sides of the saw blade on the table.
Attention: Danger of accidents!
Wear safety shoes.
Attention: Danger of accidents!
Read the operating manual before
commissioning
5. Operator training
• Pass the safety instructions on to all persons who work on the machine.
• The operating personnel must be at least 18 years of age. Trainees must be at least 16 years of age and may only work
on the machine under supervision.
• Personnel working on the machine must not be distracted.
• Keep children away from the mains-connected machine.
• Wear tight-fitting clothes. Remove jewellery, rings and watches.
• Ensure that all of the safety information and danger notices on the machine are in legible condition.
• Caution when working: Danger of injury for fingers and hands due to the rotating cutting tool.
• Regular breaks must be taken during operation.
• Safety shoes and protective clothing must be worn during operation.
6. Technical data
Item number
Dimensions
Overall length
Overall width
Overall height / table height
Table size
Saw blade ø
Saw blade nut tightening torque
Engine idle speed
Cutting speed Saw blade
Weight
Drive
Engine
Rated input P1
Power output P2
Operating mode
Nominal current
Operating data
Log cutting height
Reversible cut
1905117902, 59051169969
mm
mm
mm 1210 / 850
mm
mm
Nm
1/min
m/sec
kg
V/Hz 380 - 400 / 50
kW
kW
S6 / 40%
A
max. mm
min. mm
max. mm
Subject to technical changes!
www.scheppach.com
Attention: Danger of accidents!
Wear hearing protection.
Wear safety goggles.
Attention!
Tool continues to run after
power disconnected!
Disconnect the device from the
power supply before carrying out
any maintenance, cleaning or
repair work!
ke 70m
1905116902, 59051179969
1460
855
1400 x 850
Ø 700 x 30 x 4.5 x 3.5 Z 42 (HW)
90
1400
51
172
5.2
4
16
250
60
250
ke d700
1420
860
1250 / 850
1400
51
149
380 - 400 / 50
5.2
4
S6 / 40%
16
230
