PRODUCT PARTS �� 1
(1) Adjustment Handle
(2) Backrest
(3) Carrying Handle
(4) Booster
(5) ISOFIX Locking Arms
(6) ISOFIX Anchorage Points
(7) ISOFIX Safety Indicator
(8) ISOFIX Release Buttons
(9) Adjustable Headrest
THE CORRECT POSITION IN THE VEHICLE
This is an i-Size booster seat Enhanced Child Restraint System. It is appro-
ved according to UN Regulation No. R129/04, for use in i-Size compatible ve-
hicle seating positions as indicated by vehicle manufacturers in their vehicle
user guides. If your vehicle does not have an i-Size seating position, please
check the vehicle type list. You can obtain the most up-to-date version from
go.cybex-online.com/solution-g2-car-compatibility.
With retracted ISOFIX-locking arms the car seat can be used on vehicle seats
which are equipped with an automatic three point belt. For using ISOFIX please
refer to the vehicle type list for approved vehicles.
Above a child's stature of 135cm, the compatibility between the car seat
1
and your vehicle might be reduced.
Please check the vehicle type list whether the car seat can be used without
restriction in all headrest positions. In exceptional cases, the car seat may also
be used on the front passenger seat. Always comply with the recommendati-
ons of the vehicle manufacturer.
CARRY AND UNFOLD THE CAR SEAT
The car seat can be folded for carrying. Pull the adjustment handle (1) and fold
down the backrest (2) until it clicks into place with an audible "CLICK".
Ensure that before folding the car seat the cup holder, if installed on the
1
car seat, has been removed.
Use the carrying handle (3) located on the back of the car seat to carry it.
To unfold the car seat, pull the adjustment handle (1) and open the backrest (2)
until it clicks into place with an audible "CLICK".
(10) Headrest Height Adjuster
(11) Lap Belt Guide
(12) Shoulder Belt Guide
(13) Linear Side-impact
Protection (L.S.P.)
(14) Side Impact Protection
Release Button
(15) Reclining Headrest
(16) User Guide Storage Compartment
�� 2
INSTALLING THE CAR SEAT IN THE VEHICLE
1. Always ensure that...
the backrests in the vehicle are locked in their upright position.
•
when installing the child seat on the front passenger seat, adjust the vehic-
•
le seat as far back as possible without affecting the belt routing.
2. Use the adjustment handle (1) under the booster (4) and pull the two
ISOFIX-locking arms (5) to their furthest extent.
3. Now twist the ISOFIX-locking arms (5) 180° so that they are facing the di-
rection of the ISOFIX-anchorage points (6).
4. Place the car seat on the appropriate seat in the car.
5. Push the two ISOFIX-locking arms (5) into the ISOFIX-anchorage points (6)
until these lock into place with an audible "CLICK".
6. Use the adjustment handle (1) and push the car seat against the vehicle
seat until it is fully aligned with the backrest.
If the headrest of the vehicle is in the way, pull it upwards to its furthest
1
extent or remove it completely (except in rear-facing vehicle seats).
7. Ensure the seat is secure by trying to pull it out of the ISOFIX-anchorage
points (6). The green safety indicators (7) must be clearly visible on both
sides of the seat.
8. In case the seat is used without ISOFIX, it can be stored away on the bot-
tom of the seat.
By using ISOFIX, a connection to the vehicle is created which increases
1
your child's safety. Your child still needs to be secured with the three-point
belt of the vehicle.
REMOVING THE CAR SEAT FROM THE VEHICLE
Perform the installation steps in the reverse order.
1. Unlock the ISOFIX Locking Arms (5) on both sides by pushing the ISOFIX
Release Buttons (8) and pulling them back simultaneously.
2. Pull the seat away from the ISOFIX Anchorage Points (6).
3. Remove the car seat and push the ISOFIX Locking Arms (5) fully back into
the transport position.
ADJUSTING THE HEADREST
The Adjustable Headrest (9) can be adjusted by using the Headrest Height
Adjuster (10) at the back of the headrest (9). Adjust the headrest so that max. 2
cm remain between the child's shoulder and the headrest.
The height of the headrest can still be adjusted while the car seat is
1
installed in the car.
�� 3,4
�� 3,4
�� 6,7
