CYBEX Gold SOLUTION G2 Benutzerhandbuch Seite 14

EN CORRECT INSTALLATION MODE
SECURING THE CHILD
1. Route the vehicle seat belt around your child and insert the belt tongue into
the belt buckle. It must lock into place with an audible "CLICK".
2. Place the lap belt in the green coloured lap belt guides (11) of the car seat.
3. Pull the lap belt tight.
4. On the side of the car seat next to the belt buckle, the shoulder belt and the
lap belt must be inserted together in the lap belt guide (11).
5. Feed the shoulder belt through the shoulder belt guide (12) until it is inside
the belt guide.
6. Pull the shoulder belt tight.
7. Ensure that the shoulder belt runs across your child's clavicle and does not
touch your child's neck. If necessary, adjust the height of the headrest (9)
to change the position of the belt.
ADJUSTING THE RECLINE POSITIONS
This car seat offers various sitting positions.
1. To put the car seat in the desired recline position, press the adjustment
handle (1) on the underside of the front area of the booster (4) and pull the
car seat forward.
2. To return the car seat from the recline position to the sitting position, press
the adjustment handle (1) again and guide the seat upwards with light pres-
sure against the booster (4).
The car seat has to be adjusted to one of the sitting positions before the
1
child is seated.
8
100 cm – 150 cm
�� 8,9
�� 5
LINEAR SIDE-IMPACT PROTECTION (L.S.P.)
If the Linear Side-impact Protection (L.S.P.) (13) is in conflict with the car door
or if it affects the amount of space left on the passenger seat, it is possible
to detach it. To do so, press the side impact protection release button (14).
To reach this button, the cover of the backrest (2) needs to be removed. To
reattach the L.S.P. (13) to the car seat, follow the removal instructions in the
reverse order.
RECLINING HEADREST �� 6
The reclining headrest (15) helps to prevent the child's head from dangerously
tipping forward during sleep. It can be set on two positions.
To adjust the reclining headrest (15), lift it and slide it forward or backward to
the desired position.
The child's head should always be in contact with the reclining headrest.
1
REMOVING AND REATTACHING THE SEAT COVER
The cover of the car seat consists of four parts (headrest (x2), backrest, boos-
ter). These are held in position at several places by press studs, velcro and
elastic bands.
Once all attachments have been released, the single parts of the cover can be
removed. In order to put the covers back on the seat, follow the removal inst-
ructions in the reverse order.
The cover may only be washed at 30 °C with a delicate wash program
1
otherwise it may result in discoloration of the cover fabric. Please wash
the cover separately from other laundry and do not dry in the dryer or in
direct sunlight!
MANUFACTURER'S WARRANTY AND DISPOSAL REGULATIONS
CYBEX GmbH (Riedingerstr. 18, 95448 Bayreuth, Germany) gi-
ves you years warranty on this product. The warranty is valid in the
country, where this product was initially sold by a retailer to a custo-
mer. The contents of the warranty and all essential information requi-
red for the assertion of the warranty can be found on our homepage
go.cybex-online.com/manufacturer-warranty-car-seats.
If a warranty is shown in the article description, your legal rights against us for
defects remain unaffected.
Please observe the waste disposal regulations in your country.
�� 10
