In cases of stubborn dirt you can move
the device backwards and forwards on
the spot (like a scrubber), until the
required result is achieved.
CAUTION
RISK OF INJURY FROM RUNNING
BRUSHING TOOL!

Never lift the device off the ground
whilst switched on during work as
there is danger of entanglement!
6.2 User information

Do not remove any wet weeds with the
device.

Never clean wood decks or wood
terraces with the joint brush.

Only clean joints that are intact.
Damaged or crumbling joints or joints
with cracks should not be cleaned with
the device.

Rinse the cleaned surfaces thoroughly
after cleaning.

Worn brushes i.e. frayed wire bristles
should be replaced in good time.
To prevent damaging the device, it is
essential that the joint brush is replaced
when the diameter is < 90 mm.
6.3 Replacing the joint brush
Figures 26 - 30

Switch off the device and disconnect the
power cord (D) from the power supply.
26
Open the locking device (L)
joint brush unit (K), as shown in the
illustration, and remove the joint
brush unit.
27
Unscrew the hexagon socket screw
3-4 turns so far out of the joint brush
housing, until safety guard (I) can easi-
ly be twisted and pulled off.
28
Now press lock button (R) which blocks
the drive shaft and unscrew the hexagon
socket screw, which fixes the joint brush
(K), from the drive shaft (
the disc from the joint brush.
ATTENTION
Improper use of the device poses a risk
of damage to property! You should
therefore observe the following safety
instruction:

Never activate the lock button (R)
when the joint brush is running.
29
Pull the joint brush (K) from the flange
on the shaft and exchange it for a new
one.
30
Assembly is carried out in reverse order
(

After maintenance or cleaning ensure
that all screws, bolts, nuts and safety
devices are secure and assembled.
7 Decommissioning
& Storage
7.1 Decommissioning
Figure 31

Take the device out of operation by
releasing the ON/OFF safety switch (E)
in the handle.

Disconnect the device from the power
supply.
CAUTION
RISK OF INJURY FROM RUNNING
BRUSHING TOOL!

Never lift the device off the ground
whilst switching it off as there is dan-
ger of entanglement!
of the 31
Do not put the device down on the
brush during work breaks or after use
as this will damage the bristles.
Always hang the device up or lie it
down as shown in the illustration.
7.2 Storage
CAUTION
You may be exposed to hazards that
could injure you when handling the
device.
). Remove
You must therefore store the device
away from children.

Remove any dirt and debris.

Store the device hung up, dry and
protected from frost.
