3.2 Elements of the device
A Ergonomic handle
B Lock-off button
C Cable strain relief
D Power cord
E ON/OFF safety switch
F Additional handle
G Telescopic tube
H Screw connection telescopic tube
I Safety guard for joint brush
4 Technical data
MultiBrush SC PLUS
Item number:
Voltage:
Output:
Rotational speed of joint brush:
Rotational speed of surface brush:
Dimensions
Device width:
Device height (min):
Device height (max):
Device weight with joint brush:
Device weight with surface brush:
*Hand-Arm vibration value:
*Sound pressure level L PA :
*Sound power level L WA :
Protection class:
* Also applies to the use of the following accessories:
- 729160.0000 Law aerator roller (special accessories)
- 729161.0000 Scarifier roller (special accessories)
- 728964.0000 CUT & BRUSH (special accessories)
5 Assembly
Figures 1 - 9
NOTE!
1
Before your device can be put into
operation, it must be assembled.

After removing from the packaging,
loosen screw connection (H)
Next, turn handle (A) 45° as shown in
3
fig ure and adjust the length of
the telescopic tube (G) according to
your body height, as illustrated.
5 locking positions are available.
4
In the selected position, turn handle
(A) a further 45° and tighten the
height of the telescopic tube (G) with
J Guiding wheel
K Joint brush unit
L Locking device (2 x left/right)
M Motor/gear unit
N Guide arm (removable)
O Surface brush
P Adjustable safety guard
Q Drive arm (removable)
R Lock button
S Adjustment wheel for speed control
(Speed control)
000298.0000
230 VAC / 50 Hz
500 Watt
650 rpm to 1600 rpm
450 rpm to 1100 rpm
Surface brush 24.0 cm // Joint brush 28 cm
Surface brush 1.15 m // Joint brush 1.04 m
Surface brush 1.35 m // Joint brush 1.24 m
2.9 kg
3.6 kg
< 3.1 m/s 2 (+/- 1.5 m/s
71 dB(A)
92 dB(A)
II
the screw connection (H) by hand.

As the device should always be
guided and operated with two hands,
fit the additional handle (F) as shown
in the figure
and screw the additional handle (F)
tightly into place
7
Open the
2
.
of the drive arm (Q) and, with the
lock applied, (L) put the drive arm (Q)
with safety guard (P), onto the drive
side of the motor/gear unit (M), as
illustrated. Release the spring-loaded
lock (L), the drive arm is locked when
the locking device independently
returns to its original position
24
2 )
5
, adjust the height
6
.
locking device (L)
.
