Technische Daten
525-600 V
Gehäusetyp Leistung [kW]
A3 5.5-7.5
B3 11-18
B4 22-37
C3 45-55
C4 75-90
A5 1.1-7.5
B1 11-18
B2 22-30
C1 37-55
C2 75-90
Tabelle 8.10 525-600 V, Baugrößen A, B und C
8.8.2 UL Compliance
3x200-240 V
Power Bussmann
[kW]
Type RK1 1)
1.1 KTN-R-10
1.5 KTN-R-15
2.2 KTN-R-20
3.0 KTN-R-25
3.7 KTN-R-30
5.5/7.5 KTN-R-50
11 KTN-R-60
15 KTN-R-80
18.5-22 KTN-R-125
30 KTN-R-150
37 KTN-R-200
45 KTN-R-250
Tabelle 8.11 3x200-240 V, Enclosure Types A, B and C
MG16E303
Produkthandbuch
Empfohlene
Sicherungsgröße max. Sicherungsgröße
gG-10 (5,5)
gG-16 (7,5)
gG-25 (11)
gG-32 (15-18)
gG-40 (22)
gG-50 (30)
gG-63 (37)
gG-63 (45)
gG-100 (55)
aR-160 (75)
aR-200 (90)
gG-10 (1,1-5,5)
gG-16 (7,5)
gG-25 (11)
gG-32 (15)
gG-40 (18,5)
gG-50 (22)
gG-63 (30)
gG-63 (37) gG-160 (37-45)
gG-100 (45)
aR-160 (55)
aR-200 (75-90)
Recommended max. fuse
Bussmann Bussmann
Type J Type T
JKS-10 JJN-10
JKS-15 JJN-15
JKS-20 JJN-20
JKS-25 JJN-25
JKS-30 JJN-30
KS-50 JJN-50
JKS-60 JJN-60
JKS-80 JJN-80
JKS-125 JJN-125
JKS-150 JJN-150
JKS-200 JJN-200
JKS-250 JJN-250
Danfoss A/S © Version 2014-06-04 Alle Rechte vorbehalten.
Empfohlene Empfohlener
Trennschalter
(Moeller)
gG-32 PKZM0-25
gG-63 PKZM4-50
gG-125 NZMB1-A100
gG-150 NZMB2-A200
aR-250 NZMB2-A250
gG-32 PKZM0-25
gG-80 PKZM4-63
gG-100 NZMB1-A100
NZMB2-A200
aR-250 (55)
aR-250 NZMB2-A250
Bussmann Bussmann
Type CC Type CC
FNQ-R-10 KTK-R-10
FNQ-R-15 KTK-R-15
FNQ-R-20 KTK-R-20
FNQ-R-25 KTK-R-25
FNQ-R-30 KTK-R-30
-
-
-
-
-
-
-
Max. Abschaltwert
[A]
25
50
100
150
250
25
63
100
160
250
Bussmann
Type CC
LP-CC-10
LP-CC-15
LP-CC-20
LP-CC-25
LP-CC-30
- -
- -
- -
- -
- -
- -
- -
63
8 8
