Operating controls and appliance parts
(12)
(11)
(10) (9)
(1) Lid for coffee bean container
(2) Grinding level control
(3) Control panel
(4) Display
(5) Coffee and milk outlet
(6) Coffee grounds container
(7) Residual water tray
(8) Drip tray with drip grid
Operating controls and appliance parts
(10) Cover flap of the brewing
(11) Water tank
(12) Coffee bean container
(1)
(2)
(3)
(4)
(5)
(9) Brewing unit
unit
Page EN-13
