6.4.2
Eliminating faults
Troubleshooting
Fault
Possible causes
No or faulty
Electrical connec-
output signal
tion faulty.
False air gap be-
tween the measur-
ing surface and the
target wheel
Measuring surface
or target wheel
damaged.
Check the position
of the signal track
and reference track.
Incorrect configura-
tion of measuring
system
6.5
Service, repair
Questions about troubleshooting or repair shipments are answered by the service de-
partment or the employees at the company locations.
Service:
Company locations: Contact details
Have the following information ready in case of inquiries:
●
Product identifier (see rating plate imprint)
●
Serial number (see rating plate imprint)
●
Error description
GEL 2444M
Service, repair
Remedy
Check that all electrical connections between
the MiniCODER and the power supply and
the evaluation electronics are correct and that
contacts are secure and dry.
Check that the required value is maintained
under all (climatic) conditions, valid for a full
target wheel revolution.
Use a torque wrench to check that the screws
are tight.
Replace damaged component.
Determine the cause of the damage and recti-
fy it.
Mount the measuring system so that the
reference track and the signal track match the
corresponding sensor elements in the
MiniCODER.
Connect the MiniCODER to the mobile ser-
vice unit.
Check the tooth number.
Check the resolution.
Check assignment of the direction of rotation.
Check the function of measuring system.
Analyze error messages (Alarm and warning
table
the error.
Remove the mobile service unit.
Web:
www.lenord.com
→ page 99
