5 Mounting and connection
5.4
Mounting and connecting the MiniCODER
Magnetic field!
CAUTION
●
Exercise caution when approaching the product to metallic objects.
●
Hold the product in such a way as to avoid crushing of fingers or
skin.
NOTICE
Incorrect handling of measuring surface!
●
Avoid sudden contact between the measuring surface and other ob-
jects.
●
Do not destroy or remove the protective layer on the measuring sur-
face.
●
Observe the assembly sequence.
NOTICE
Incorrect handling of connection components!
●
Observe minimum bending radiuses.
5.4.1
Accessories, tools and consumables
●
2 M4 screws (recommendation: DIN 912 M4×10) with spring washers and
washers
●
Torque wrench
(depending on the screw used and the material of the mounting fixture)
●
Threadlocker
(for example Loctite 274 depending on the location and purpose of use)
●
Distance gauge supplied
●
Lint-free cloth, moistened with a non-corrosive cleaning agent
●
As required: Mobile service unit
●
Accessories and tools for connecting the MiniCODER to the
higher level control system
(depending on the connection type)
82
Mounting and connecting the MiniCODER
Lenord+Bauer
GEL 2444M
