BIKE SET-UP
In general, we are running the rebound settings at the slower end of the range provided at each pressure and the compression settings
at the lighter end of the provided range. For example, if you are running 200 psi in the shock, the range for LSR is listed as 12-14
clicks in from open; We recommend starting at 14. For HSR the range is 4-5 clicks in from open; We recommend starting at 5. On the
compression side for LSC, at 200 psi in the shock, the range is 7-9 clicks in from open; We recommend starting at 7 clicks in. For HSC the
range is 3-4 clicks in from open; We recommend starting at 3. If you follow this same process for the pressure that you are running then
you'll have an excellent starting set up that may not require any further adjustment. The bold numbers in the chart refer to how many
clicks clockwise from the open setting the dials should be set. Fox sets up shocks from the closed position, so that has been provided in
parentheses.
For further detail, FOX provides a complete tuning guide for the Float X2 Air shock on their website at
Rebound & Compression Damping Settings Table for FOX Float X2
Air Spring
Pressure [psi]
90
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
250
260
270
280
290
300
pivotcycles.com
SUGGESTED SETTINGS
FOX FLOAT X2
Baseline LSR Baseline HSR
(3mm hex) (2mm hex)
Clicks from OPEN (Clicks from CLOSED)
2-4 (16-18) OPEN-1 (7-8)
3-5 (15-17) OPEN-1 (7-8)
4-6 (14-16) 1-2 (6-7)
5-7 (13-15) 1-2 (6-7)
6-8 (12-14) 2-3 (5-6)
7-9 (11-13) 2-3 (5-6)
8-10 (10-12) 2-3 (5-6)
9-11 (9-11) 3-4 (4-5)
10-12 (8-10) 3-4 (4-5)
11-13 (7-9) 3-4 (4-5)
11-13 (7-9) 4-5 (3-4)
12-14 (6-8) 4-5 (3-4)
12-14 (6-8) 4-5 (3-4)
13-15 (5-7) 5-6 (2-3)
14-16 (4-6) 5-6 (2-3)
15-17 (3-5) 5-6 (2-3)
16-18 (2-4) 5-6 (2-3)
16-18 (2-4) 6-7 (1-2)
17-19 (1-3) 6-7 (1-2)
17-19 (1-3) 6-7 (1-2)
17-19 (1-3) 7-8 (0-1)
18-19 (1-2) 7-8 (0-1)
info@pivotcycles.com
Baseline HSC
Baseline LSC
(3mm hex)
(6mm hex)
OPEN-2 (16-18) OPEN-1 (7-8)
OPEN-2 (16-18) OPEN-1 (7-8)
1-3 (15-17) OPEN-1 (7-8)
1-3 (15-17) OPEN-1 (7-8)
2-4 (14-16) 1-2 (6-7)
2-4 (14-16) 1-2 (6-7)
3-5 (13-15) 1-2 (6-7)
3-5 (13-15) 1-2 (6-7)
4-6 (12-14) 2-3 (5-6)
5-7 (11-13) 2-3 (5-6)
6-8 (10-12) 2-3 (5-6)
7-9 (9-11) 3-4 (4-5)
8-10 (8-10) 3-4 (4-5)
9-11 (7-9) 3-4 (4-5)
10-12 (6-8) 3-4 (4-5)
11-13 (5-7) 4-5 (3-4)
12-14 (4-6) 4-5 (3-4)
14-16 (2-4) 4-5 (3-4)
14-16 (2-4) 4-5 (3-4)
14-16 (2-4) 5-6 (2-3)
15-17 (1-3) 5-6 (2-3)
15-17 (1-3) 5-6 (2-3)
