MMA welding
Connection and notes
Schließen Sie das Elektrodenhalterkabel an den Pluspol (6) und das Massekabel an den
Minuspol (9) an. Beachten Sie auch die Schweißpolaritäten und angegebenen Stärken auf
der Elektrodenpackung.
Selection of welding mode and welding current setting
Choose MMA with selection button (4). Then set welding current with button 3. The
following values serve as guidelines:
electrode diameter mm
current A
Please always observe the guide values indicated on the electrode package!
Switch on the mains switch (10) on the unit. Connect the earth clamp and the workpiece.
Clamp an appropriate electrode into the electrode holder and put on a sight shield and
gloves.
Start welding
Ignite the arc by touching the electrode to the workpiece. If the distance of the electrode
to the workpiece is correct, a stable arc will burn and melt the electrode.
Stop welding
Pull the electrode away from the workpiece, the arc will break. Remove the electrode
from the electrode holder when the welder is not in use. (Caution, let it cool down
beforehand, danger of burns!)
Do not switch off the appliance immediately, allow the fan to run during both welding
processes to cool the components. This will increase the lifetime of your welding machine.
TIG welding (Lift TIG DC)
Compatible torches
Please use TIG torches with 9 mm current coupling, gas regulating valve on the handle and
separately guided gas connection. The shielding gas is not controlled by the unit but taken
directly from the pressure regulator. We recommend our WELDINGER TIG hose package
SR17V (art.no. 5603) with 9 mm mandrel.
Connect the TIG hose package to the unit, the power connection to the (-) terminal, the
earth cable to the positive terminal, the gas hose to the gas regulator. Unscrew the argon
bottle and adjust the gas quantity according to the application. We recommend opening
the gas valve on the TIG torch slowly at the beginning and setting a gas flow rate of
12l/min.
As basic equipment for the TIG torch we recommend our WELDINGER TIGSET1 (Art.No.
4141). It contains all important wear parts so that you always have the right part at hand.
Preparation of the machine
First assemble the hose assembly with its torch. To do this, insert the clamping sleeve into
the torch head and screw in the clamping sleeve housing. Then screw in the torch cap.
1,5
2,0
30-50
40-70
40
2,5
3,25
50-100
90-150
4
130-160
