*Before subscribing the SmartLink service, please make sure that you have a good command of

the SmartLink system. If you have any questions regarding the SmartLink Diagnostics, please

contact the service personnel of the office in your region or your local distributor.

The SmartLink system is powerful remote diagnostics solution developed by LAUNCH. The system consists of SmartLink C dongle (for technicians seeking a trusted second opinion and

additional expertise on various vehicle issues), SmartLink Service Platform (for SmartLink C posting assistance request and SmartLink B accepting order) and SmartLink B dongle (for

service provider or master technician). They are inseparable from each other for any SmartLink Diag. Follow the steps below to perform a SmartLink session.

Post request

Bind

the

SmartLink

Connection & setup

Connect the vehicle's DLC and crossover cable.

Wait for partner's assistance

dongle (plus the compatible diagnostic tool).

Start Diagnostics

Turn on the ignition key and start the diagnosis. After the diagnostic session is completed, unplug the crossover cable, terminate the operation and rate the service.

Below illustrates how the SmartLink system works.

SmartLink C V2.0 dongle

(Technician)

Crossover Cable

Assistance Demander

* During the remote diagnosis, please do not disconnect the vehicle and the network (the network broadband of 100Mb and above is recommended). In addition, a SmartLink C V2.0 dongle can only receive one

remote diagnosis operation at a time.

and

post

remote

diagnostics request in

After the remote master technician accepts the order, he will provide professional technical service to you using the SmartLink B/SmartLink B V2.0

Vehicle's DLC

Diagnostic Cable

Internet

the SmartLink module (*Only after the SmartLink C V2.0 dongle is successfully bound can the request be posted).

Service Provider

(The communication
