Scheppach HM140L Originalbetriebsanleitung Seite 15

1. Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer,
We hope your new product brings you much enjoyment
and success.
Note:
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability
for damage to the product or caused by the product
arising from:
• Improper handling
• Non-compliance with the operating manual
• Repairs carried out by third parties, unauthorised
specialists
• Installing and replacing non-original spare parts
• Application other than specified
• Failure of the electrical system in the event of the
electrical regulations and VDE provisions 0100,
DIN 57113 / VDE0113 not being observed
Note:
Read through the complete text in the operating manu-
al before installing and commissioning the device.
This operating manual should help you to familiarise
yourself with your product and to use it for its intended
purpose.
The operating manual includes important instruc-
tions for the safe, proper and economic operation of
the product, for avoiding danger, for minimising repair
costs and downtimes and for increasing the reliability
and extending the service life of the product.
In addition to the safety instructions in this operating
manual, you must also observe the regulations appli-
cable to the operation of the product in your country.
Keep the operating manual package with the power
tool at all times and store it in a plastic cover to pro-
tect it from dirt and moisture. They must be read and
carefully observed by all operating personnel before
starting the work.
The product may only be used by personnel who have
been trained to use it and who have been instructed
with respect to the associated hazards.
The required minimum age must be observed.
28 | GB www.scheppach.com
In addition to the safety instructions in this operating
manual and the separate regulations of your country,
the generally recognised technical rules relating to the
operation of such products must also be observed.
We accept no liability for accidents or damage that
occur due to a failure to observe this manual and the
safety instructions.
2. Product description (Fig. 1 - 17)
1. Handle
2. On/off switch
3. Locking switch
4. Moving saw blade guard
5. Moveable stop rail
6. Stop rail
7. Workpiece support
8. Fixed saw table
9. Table inlay
10. Locking handle
11. Indexed position lever
12. Pointer
13. Scale
14. Rotary table
15. Clamping device
16. Set screw for moveable stop rail
17. Laser / LED
18. Dust bag
19. Machine head
20. Sawing shaft lock
21. Machine head locking pin
22. Scale
23. Pointer
24. Locking screw (incline machine head)
24a. Locking pin
25. Cable routing
26. Slide rail locking screw
27. Screw for cutting depth limiting
28. Stop for cutting depth limiting
29. Adjustment screw (45°)
30. Adjustment screw (90°)
31. Locking screw for workpiece support
32. Laser screw
33. Outer flange
34. Flange screw
35. Saw blade
36. Inner flange
37. Laser on/off switch
a. 90° engineers square (not included in the scope of
delivery)
b. 45° engineers square (not included in the scope of
delivery)
c. Hexagon spanner
3. Scope of delivery
• Sliding cross-cut mitre saw
• 1 x Clamping device (15)
• 2 x Workpiece supports (7)
• Dust bag (18)
• Hexagon spanner (c)
• Operating manual
4. Proper use
The mitre and trim saw is used for the cutting of wood
and plastic, according to the machine size. The saw is
not suitable for the cutting of firewood.
Warning! Do not use the device to cut materials other
than those described in the operating manual.
Warning! The supplied saw blade is only intended for
the sawing of wood! Do not use this blade for sawing
firewood!
The product may only be used in the intended manner.
Any use beyond this is improper. The user/operator, not
the manufacturer, is responsible for damages or inju-
ries of any type resulting from this.
An element of the intended use is also the observance
of the safety instructions, as well as the assembly in-
structions and operating information in the operating
manual.
Only suitable saw blades may be used for the machine.
The use of any type of cutting wheels is prohibited.
The product may only be operated with original parts
and original accessories from the manufacturer.
The safety, operating and maintenance specifications
of the manufacturer, as well as the dimensions speci-
fied in the technical data, must be observed.
Persons who operate and maintain the product must be
familiar with the manual and must be informed about
potential dangers.
The liability of the manufacturer and resulting damages
are excluded in the event of modifications of the prod-
uct.
www.scheppach.com
Please note that our equipment was not designed with
the intention of use for commercial or industrial pur-
poses. We assume no guarantee if the device is used
in commercial or industrial applications, or for equiva-
lent work.
5. Safety instructions
General power tool safety warnings
m WARNING - Read all safety information, in-
structions, illustrations and technical data for this
product.
Failure to follow all instructions listed below may result
in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" used in the safety instructions
refers to mains-powered electrical tools (with a mains
cable) and battery-powered electrical tools (without a
mains cable).
1. Work area safety
a) Keep your work area clean and well-lit. Clut-
tered or dark areas invite accidents.
b) Do not operate power tools in explosive at-
mospheres, such as in the presence of flam-
mable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while op-
erating a power tool. Distractions can cause you
to lose control.
2. Electrical safety
a) Power tool plugs must match the outlet. Nev-
er modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
Avoid body contact with earthed or grounded
b)
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of elec-
tric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet con-
ditions. Water entering a power tool will increase
the risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts.
