PeakTech 2005 Bedienungsanleitung Seite 39

3.3. DC Current
Range
2 mA
20 mA
200 mA
10 A
Overload protection:
0,2A / 600V: 5 x 20 mm fuse in mA-Input
10A / 600V: 5 x 20 mm fuse in 10A-Input (Fast-blow fuse)
10A for max. 10 sec.
3.4. AC Current
Range
2 mA
20 mA
200 mA
10 A
Overload protection
0,2A / 600V: 5 x 20 mm fuse in mA-Input
10A / 600V: 5 x 20 mm fuse in 10A-Input (Fast-blow fuse)
10A for max. 10 sec.
Frequency - range: 40 ... 200Hz
3.5. Resistance
Range

200
2 k
20 k
200 k
2 M
20 M
2000 M
Overload protection: 250V DC/AC
Resolution
1 µA
10 µA
100 µA
10 mA
Resolution
1 µA
10 µA
100 µA
10 mA
Resolution
0,1 

1

10

100
1 k
10 k
1 M
Accuracy
± 0,8% rdg. + 3 dgt.
± 1,2% rdg. + 4 dgt.
± 2,0% rdg. + 5 dgt.
Accuracy
± 1,0% rdg. + 5 dgt.
± 2,0% rdg. + 5 dgt.
± 3,0% rdg. + 10 dgt.
Accuracy
± 0,8% rdg.+ 5 dgt.
± 0,8% rdg.+ 3 dgt.
± 1,0% rdg.+15 dgt.
± 5,0% (rdg.-10) +20 dgt.
pp
-38-
