1.1. Safety Symbols
The following symbols are imprinted on the front panel of
the meter to remind you of measurement limitations and
safety.
10 A The maximum current that you can measure at this
terminal is 10A DC/AC. This terminal is fuse
protected by F 10A/600 V fuse. When using this
range with high current, keep the duty cycle to
10 seconds on load and 15 minutes off load.
mA The maximum current that you can measure with
this terminal is 200mA that is fuse protected by
200mA/600 V fuse.
Max.
To avoid electrical shock or instrument damage, do
not connect the COM Terminal to any source of
600V DC/AC with respect to earth ground.
The maximum voltage this meter can measure is
600V DC or AC. Be exceptionally careful when
measuring high voltages. Do not touch the
terminals or test leads ends
Refer to the complete operating instructions.
Indicates protection class II, Double Insulation
CATII Overvoltage category III
