EN
ENVIRONMENT
The device is delivered in a package to protect it against any possible
transport damage. The packaging is made from non-processed
material and can be recycled. Throw the materials to appropriate
colour containers for selective waste collection.
Protect the environment and do not throw used batteries
into household wastes. Return them to the point of sale
or a special recycling centre.
Used electrical equipment (including the computer and
power supply) are recyclable. Do not throw them out with
household waste as they may contain substances dangerous to the
health and environment. You can actively contribute to sustainable
use of natural resources and the protection of the natural
environment by handing the used device to a recycling centre for used
electrical devices.
ASSEMBLY
The device must be assembled carefully by an adult. In case of doubt,
ask a more experienced person for help.
•
Prior to the assembly, make sure the set contains all
the listed elements and whether none of the parts was
damaged during transport. If any parts are missing or you have
any other reservations, contact the seller.
•
Have a look at the drawings and explanations and follow the
assembly manual when assembling the device.
•
Be careful during the assembly. There is a risk of injury when
using the tools and parts.
•
Remember to keep your surroundings safe. Do not let tools
and parts lie around in chaos. Remember that plastic foil and
bags pose o suffocation risk to small children.
•
Assembly parts necessary for a specific step in
the assembly manual are shown in pictures and included in
instructions. Use the elements indicated in the assembly
manual.
•
Do not tighten parts completely during the first stages
of the assembly. Tighten connections after all parts are placed
and fitted properly.
•
The manufacturer may have assembled some parts.
ASSEMBLY DIAGRAM (→ See page 2)
ATTENTION! Do not use parts other than those provided by the
manufacturer.
PARTS LIST
NO.
DESCRIPTION
1
Main frame
2
Bottom frame
3
Treadmill columns
4
Upper frame
5
Tilt frame
6
Motor frame
7
Front roller
8
Rear roller
9
Cylinder
10
Gear plate t15*520*1130
11
Gear belt t1.4*400*2520
12
Multi-ribbed belt
13
Computer
14
Engine top cover
15
Rear roller cover - left
16
Rear roller cover - right
17
Rear frame cover
18
Frame cover left side
19
Right side frame panel
20
Frame end
21
Transport wheel
22
Wheel washer
23
Rubber shock pads
24
Shock absorber
25
Rubber pads
26
Rubber cushioning pads
27
Foam handles
17
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
QUANTITY
72
73
1
74
1
2
75
1
76
77
1
1
ASSEMBLY MANUAL (→ See page 3)
1
CAUTION! Follow the steps below during the assembly and use tools
2
supplied with the product. Prepare sufficient space for the assembly
1
operation. It is advisable to assemble the product with another person
1
because of the weight of some elements.
1
1
FOLDING AND UNFOLDING (→ See page 5)
1
1
FOLDING THE DEVICE
1
NOTE! Before assembling, check carefully that all screws are
1
tightened.
1
NOTE! Be careful with your hands and fingers when folding so that
1
they do not get crushed.
1
Lift the running belt of the device to the horizontal position until the
2
lock clicks.
4
2
UNFOLDING THE DEVICE
2
PLEASE NOTE! Ensure there are no third party or animals in the
8
immediate treadmill vicinity when its belt is lowered.
4
Hold the running belt and release the folding lock (indicated with the
2
arrow). Lower the belt to the railing level. The belt will now descend
2
automatically.
Power cable clamp 6W3-4
Electrical connector
Fuse
Power cable
Double cable
Single wire
Grounding
Tilt motor
Motor
Magnetic ring
Control board
Tilt angle adjustment button
Speed adjustment button
Signal cable
Computer
Computer cable
Safety key
Sensor
Computer decal
Wrench 17*13*14* Φ5*70
Allen wrench 6# 80*80 mm
Cable
Sticky battens
Bolt M8*85
Screw M8*60
Screw M8*12
Bolt M8*85
Bolt M8*15
Bolt M8*30
Bolt M8*40
Bolt M8*45
Bolt M8*50
Bolt M8*60
Bolt Φ10*15*(M8*10)S17
Screw M10*45
Screw M10*60
Bolt M6*40
Bolt M4*8
Bolt M5*10
Bolt ST4*45
Bolt ST4*30
Bolt ST4*40
Bolt ST4*15
Nut M8
Nut M10
Washer Φ9* Φ16*t1.5
Washer Φ11* Φ20*t1.5
Spring washer Φ8.1* Φ12.3*t2.1
Spring washer Φ10.1* Φ14.3*t2.5
Railing end cap
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
5
4
1
2
2
1
4
3
2
3
2
4
4
1
5
8
2
4
2
6
4
16
14
6
16
6
2
4
2
