1. Place the product on its feet.
2. Insert the threaded end into the threaded hole of the pedal arm.
3. Hold the respective pedal in the thread of the pedal arm with one hand and use the span-
ner to tighten the pedals to the pedal arm with the other hand.
Attention! Tighten the right pedal clockwise and the left pedal anticlockwise.
Adjusting the pedal straps (Fig. D)
The pedal straps [5] are pre-assembled. You have the option to adjust the straps in several
widths.
1. Loosen the twist lock [6] on the pedal end by turning it to the left.
2. Adjust the pedal straps [5] by sliding them up or down to obtain the desired width.
3. Fix the setting by turning the twist lock [6] to the right.
Operation
Reducing/increasing resistance (Fig. E)
Place the product in front of you and turn the resistance screw [1a] to the right to increase
resistance and to the left to decrease resistance.
Note: On the resistance screw there are the signs + and - for adjusting the resistance.
The + represents resistance increase and the - resistance decrease.
Notes on suction cup attachment (Fig. I)
Choose a smooth surface, such as tiles, that is free of dust and grease. Avoid delicate surfa-
ces as they may be damaged.
Lightly moisten the suction cups before pressing them on. To loosen the suction cups, proceed
as follows: Pull up the hooks [1f] on the front suction cups.
Lift the product slightly. Loosen the rear suction cups one after the other by pulling on the
hooks [1f].
Replacing the battery
ATTENTION! Observe the following instructions to avoid mechanical
and electrical damage. After battery replacement, training data will
be lost.
Danger!
A battery is included in the product.
If the battery no longer works, you can replace it.
1. Lift up the top of the display [1b] with the battery compartment opener [11] and carefully
remove it (Fig. F). The battery is located on the back of the display
2. Carefully remove the empty battery from the battery receptacle [1c] and replace it with a
new battery.
