6.4 Overview of LED displays - Information
Explanation of LEDs and flashing symbols
Operating states
LED
Green Red Orange Orange
(1) (2) (3)
Alarm statuses / errors
LED
Green Red Orange Orange
(1) (2) (3)
Is a potential-free contact activated, if yes, which one? (W = warning, E = error)
1
If the error re-occurs, contact customer service
2
016-272
Acoustic
signal PFC
1
(interval)
(4)
- -
- -
- -
- -
Acoustic
signal PFC
1
(interval)
(4)
E
E
E
E
W
E
E
E
Installation and operating instructions
Item Function
no.
(1) Power LED
(2) LED Alarm
(3) Level LED
(4) Manual operation
LED
Description
Power outage, no
battery monitoring
Ready for operation
System tank full, will
be pumped out shortly
Pumping sys-
tem tank to empty
Description
Battery error
2
Power outage, mains voltage
failed, system non-functional
Level error
Max. number of runs/run-
time; wastewater pump was
switched on too often/too long
Alarm level exceeded
Relay fault, contac-
tor continuously ON,
pump runs continuously
Motor fault (motor protec-
tion switch or temperature
monitoring has triggered)
Maximum number of oper-
ating cycles exceeded
Flashing / fast flashing
/
Lights up / switched on
Switched off
Flashing alternately
Flashing simultane-
ously
Measure
Restore the mains voltage
-
No action required, waste-
water pump can be switched
off with button (8) (see "Man-
ual operation", page 30)
Measure
Replace battery
Reinstate mains volt-
age, acknowledge alarm
Acknowledge alarm
2
Wait until the level drops
below the alarm level again
Contact service technician
Check the motor
protection switch
Wait, acknowledge alarm
Can be acknowledged.
Contact customer service.
