3 Technical data
Pump
Information\pump type
Weight
Power P1/P2
Speed
Operating voltage
Rated current
max. pumping capacity
max. pumping height
Free passage
max. temperature (perma-
nent) of pumped material
Protection rating
Protection class
Operating mode
Control unit
Data
Nominal current range
Dimensions (LxWxD), mm
Weight
Standby power
Battery specification
max. operating temperature
Protection rating
Residual current
device (RCD) required
Required fuse protection
Connection type
Potential-free contact
016-272
SPF 2000
23 kg
3.0 kW / 2.5 kW
2850 rpm
400V; 50Hz
5.0 A
44 m /h
3
14 m
40 mm
40°C
IP68 (3m/48h)
I
S3 - 50%
Control unit
4.0 - 6.3 A
190 x 280 x 130
approx. 2.5 kg
2.5 W
2x 9V 6LR61
40°C
IP 54
30 mA
C16A
Direct connection
max. 42 V DC / 0.5 A
Installation and operating instructions
Fig. 1: Pumping capacity and height
