Connect sensors
Remove dummy cover.
Screw in the thread of the cable gland M16x1.5.
Push the nut of the cable gland onto the end of the cable.
Feed the wires and cable end through the opening of the
cable gland.
Insert the wires while shifting the release lever at the
same time.
Tighten the nut of the cable gland finger-tight.
4.8 Further connection possibilities
Potential-free contact
If required, signal generators or other accessories can be connected as potential-free contacts (42 V 0.5 A). The following
terminals are available for these:
Warning (event is displayed - e.g. alarm level exceeded) -normally closed-
Fault (fatal error - e.g. in electrical connection or safety systems) -normally open-
28 / 56 Installation and operating instructions 016-272
