Siemens SIMATIC RF200 Systemhandbuch Seite 41

Tabelle 4- 3 Felddaten SIMATIC RF240R
MDS D100
MDS D124
MDS D126
MDS D160
MDS D165
MDS D200
MDS D261
MDS D324
MDS D400
MDS D422
MDS D423
MDS D424
MDS D425
MDS D426
MDS D428
MDS D460
MDS D522
MDS D522
Sondervariante
MDS D524
MDS D525
MDS D526
MDS D528
MDS D560
Alle Angaben in mm.
SIMATIC RF200
Systemhandbuch, 03/2019, J31069-D0227-U001-A11-0019
Länge des Übertragungs-
fensters (L)
100
65
80
50
105
90
70
55
95
25
45
75
30
65
50
50
20
20
60
30
60
40
50
4.2 Felddaten von Transpondern und Readern
Arbeitsabstand (S )
a
2 ... 84
2 ... 53
2 ... 57
1 ... 33
2 ... 80
2 ... 69
2 ... 60
1 ... 36
2 ... 80
1 ... 12
2 ... 35
1 ... 47
1 ... 15
2 ... 45
1 ... 30
1 ... 30
1 ... 10
1 ... 10
1 ... 45
1 ... 15
2 ... 45
1 ... 30
1 ... 30
RF200-System planen
Grenzabstand (S )
g
95
60
65
37
94
78
70
40
90
15
40
53
17
55
34
34
12
12
55
17
55
35
34
41
