4.3
Motor connection
Size
View of the connector pins at
the motor
Terminal assignment
Motor cable for
Ax...Dx.SM.D
B
A
5
4
3
A
U
B
V
C
W
PE
1
Brake + (option)
2
Brake - (option)
3
Temperature detector +
4
Temperature detector -
5
–
Ax...Dx.SM.D
00H6Lx0-00yy
4x1,5 mm²; 2x1 mm²; 2x1,5 mm²;
x=0: static installation; x=1: flexible installation; yy - line length [m]
Connection
C
W
1
2
2
U
U
V
V
W
W
PE
+
Brake + (option)
-
Brake - (option)
1
Temperature detector +
2
Temperature detector -
4x2,5 mm²; 2x1 mm²; 2x1,5 mm²;
Ex.SM.D
-
V
+
U
1
Ex.SM.D
00S4319-yyyy
GB - 21
