Technical Data
Dimensions servo motor BxSMD0-xxxx
Motor type
B1
B2
B3
Speed-/torque characteristics for Ulink = 540 V (400 V class)
3,0
M
max
2,5
2,0
1,5
1,0
S1
0,5
0,0
0 1500 3000 4500 6000 7500 9000
Speed [rpm]
GB - 28
Brake
without holding brake
B1
U
ZK
(6000)
U
ZK
U
ZK
(3000)
(4000)
A
162
188
214
B2
6,0
M
max
5,0
4,0
3,0
U
ZK
(6000)
2,0
S1
1,0
U U
ZK ZK
(3000) (4000)
0,0
0 1500 3000 4500 6000 7500 9000
Speed [rpm]
21
with holding brake
194
220
246
B3
9,0
M
max
7,5
6,0
4,5
3,0
S1
1,5
0,0
0 1500 3000 4500 6000 7500 9000
Speed [rpm]
U
ZK
(4000)
U
ZK
(6000)
U
ZK
(3000)
