2. Product Description
2.1 Part Code
A 2 . S M . D 0 2 - 6 4 J 2
Cooling
Motor type
Unit type
Size/construction length
Encoder
Connection
Voltage
Speed
Design
Product Description
0: Resolver 2-pole
2: BISS Singleturn absolute encoder
9: BISS Multiturn absolute encoder
J: rotatable Y-Tech plugs
B: normally Y-Tech plugs
4: 330 V (400 V class) DC link voltage 510...690 V DC
0: 1000 rpm
1: 1500 rpm
2: 2000 rpm
2: Motor shaft without keyway and no brake
3: Motor shaft without keyway but with permanent-magnet brake
0: Self-cooling with flange B5 (1FT5 compatible)
D: Three-phase synchronous motor Dynamic Line II for H6
SM: Servo motor
A1...E3
3: 3000 rpm
4: 4000 rpm
6: 6000 rpm
GB - 7
