Connection
4.4

Encoder connection

Adjustment
of the measuring
4.4.1

BISS single-turn

BISS connector
View of the connector pins at
the motor
Encoder cable
x=4: static installation; x=5: flexible installation; yy - line length [m]
4.4.2

BISS multi-turn

Optionally the motors of the series Dynamic Line II can be provided with BISS multi-turn encoder.
4.4.3

Resolver

Resolver connector
View of the connector pins at
the motor
Encoder cable
x=4: static installation; x=5: flexible installation; yy - line length [m]
GB - 22
The measuring system of synchronous motors must be adjusted to the respec-
tive inverter. Any mis-adjustment may lead to uncontrolled motor response or
system complete failure of the motor.
10
10
View
1
12
2
11
3
4
5
9
6
8
7
00H6Lx1-00yy
View
1
12
2
11
3
4
5
9
6
8
7
00H6Lx0-00yy
No. Signal
1 Common
2 Data+
3 Clock+
8 +5V
10 Data-
11 Clock-
housing –
All other contacts are not assigned.
No. Signal
11 COS+
2 COS-
10 SIN+
1 SIN-
7 REF+
5 REF-
housing shield
All other contacts are not assigned.
Color
black
pink
green
red
blue
yellow
shielding
Color
pink
blue
green
yellow
red
black
shielding
