Operating Conditions
3.3.2

Radial forces

The endurance strength of the shaft and the bearing life (20,000 h) are decisive for the permissible radial load.
Taking the endurance strength into consideration F
cesses (acceleration, braking).
F Axial force
A
F Radial force
Q
x Length of the rotor shaft up to the center of the radial force
L Length of the rotor shaft
500
450
400
350
300
250
200
150
100
0
GB - 18
Ax.SM.D
10 20 30
x [mm]
is not permitted to be exceeded even during dynamic pro-
Q
1200
1100
1000
900
800
700
600
500
400
300
200
40
0
F
Q
F
A
x
l
Bx.SM.D
10 20 30
x [mm]
40
