5.23.5. Cane holder (optional)
Place the cane in the cane holder and then fix to the backrest.
Never climb on the pole holder and never use it as a tipping aid.
5.23.6. Spoke protector (optional)
The spoke protector is attached to the spokes with cable ties.
5.23.7. Handrim cover (optional)
Put the handrim cover over the handrim to get more grip on the handrim,
for example if you have limited hand strength.
5.23.8. Infusion / Oxygen bottle
holder (optional)
The infusion / oxygen bottle holder is attached to the lower frame
tube of your wheelchair.
The risk of the wheelchair tipping over backwards increases with the
increased load of oxygen cylinders. The use of anti-tip castors is
strongly recommended.
79 79
Leichtgewichtrollstuhl | Light weight wheelchair |
5.23.9. Carry-on bag (optional)
If you want to attach a bag to your wheelchair, hang the loops of your
bag over the back tubes of your wheelchair.
Please note that the reflectors must not be covered.
Caution: Increasing the load of the bag also
increases the risk of your wheelchair tipping over
backwards. The use of anti-tip wheels is strongly
recommended.
5.23.10. Headrest (optional)
The headrest is screwed onto the push handles.
After loosening the clamping lever or star screw, you can adjust the
position of the headrest. Then tighten the screws firmly.
