B+B Pyro Light Bedienungsanleitung Seite 32

PYRO LIGHT PYRO LIGHT / XL
| Lightweight wheelchair | Leichtgewichtrollstuhl
PYRO LIGHT XL
4.3. Overview
Illustration of the most important components (Fig. 01)
Push handle
Backrest
Armrest
Side panel
Knee lever brake
Removable axle
Lifting points
Steering whell
Footplate
63 63
Leichtgewichtrollstuhl |
4.4. Type plate and Serial number
The type plate (see fig. 02) and the serial number are located on the cross
CE Sticker & UDI Codes (Size 80 mm x 23 mm)
brace.
Manual Wheelchairs
A B
H
Model: Pyro Light
2023-08
K
L
Manufaturer logo
A
Manufacuterer information
B
Medical product
C
CE-mark
D
Fastening in cars
E
Attention! - Observe instructions for use
F
1.
Important - Observe operating instructions
G
Model designation
H
Model number
I
Max. load
J
Production date
K
UDI number
L
Serial number
M
Bischoff & Bischoff GmbH | 2021-07-26 - Revision 1 Bischoff & Bischoff GmbH | 2023-09-01 - Revision 2
PYRO LIGHT / XL
Light weight wheelchair |
PYRO LIGHT XL
C C D E
Bischoff & Bischoff GmbH
Im Stöckmädle 13
D - 76307 Karlsbad
F G
I
1330
125kg
J
M
2.
PYRO LIGHT
64 64
