5.23. Accessories
5.23.1. Anti-tip wheels (optional)
35.
The anti-tip wheels prevent the wheelchair from tipping backwards.
The anti-tip castors must have a distance of approx. 3-5 cm from the
floor (Fig. 35).
The anti-tip wheels are particularly recommended for inexperienced
wheelchair users or for wheelchair users with leg amputations.
• The anti-tip wheels are attached as a pair to the left and right of the
frame.
• First pull the rubber profiles of the tipping aid off the frame.
36.
• Slide the round profile of the anti-tip wheels onto the side frame
tube.
• Now screw the anti-tip wheels into the holes provided on the frame.
• Adjust the height by pulling the washer of the holder towards you
and then snap the tube with the anti-tip wheels into place at the
appropriate height (Fig. 36).
• The anti-tip wheels can also be used as a tipping aid when the anti-
tip wheels are raised.
77 77
Always use the anti-tip wheels in pairs.
Leichtgewichtrollstuhl | Light weight wheelchair |
5.23.2. Lap belt (optional)
A lap belt can be ordered as an option and secures users who do not have
the necessary support in the wheelchair (Fig. 37).
• The Pyro Light can be fitted with a lap belt on the back tube.
• The belt is opened and closed at the locking tab.
• You can adjust the strap length using the sliding strap tab on the
strap.
5.23.3. Therapy table (optional)
For side sections with long armrests, the table is simply pushed onto the
armrests from the front using the guides provided. To remove the
therapy table, simply pull it out again. For „desk" side sections with arm
pads, the table is placed with the enclosed guides and fastened with
star grip screws. To remove the therapy table, first loosen the star
screws and then pull the table out again.
5.23.4. Togo (optional)
The Togo push aid can be fitted to your wheelchair.
All relevant information on assembly and operation can be found in the
operating instructions for the Togo push aid.
