CLEANING THE HOT CUPBOARD
To carry out this operation, proceed as follows.
1 - Switch the appliance off and leave it to cool.
2 - Turn off the circuit-breaker to disconnect it from
the electrical mains.
3 - Clean the interior of the hot cupboard of any en-
crustations which may affect its operation.
4 - Dry the surfaces off thoroughly.

CHECKING GAS PRESSURE

To carry out this operation, proceed as follows.
1 - Turn off the gas supply tap.
2 - Pull off the knob (A).
3 - Undo the screws (C) and remove the control
panel (B).
4 - Undo the screw (D) of the pressure connection.
5 - Connect the pressure gauge (E) to the pressure
test point (F).
6 - Turn the gas supply tap back on.
7 - Light all the burners and turn the knobs to the full
flame setting (see page 9), then check that the
pressure reading complies with the values pro-
vided in the table (at the back of the manual.)
8 - Turn off the burners, disconnect the pressure
gauge and return all components to their initial
condition on completion of the operation.
C
A B
C
- 13 -
IDM-3912500800.tif
E F
D
IDM-39612100900.tif
