Digital input signals (signals from robot)

Parameters

Signal level:
-
-
Reference potential: GND = X7/2 or X12/2
NOTE!
All signal states refer to the interface input, not the robot control.

Welding start

Pin X2/4
The "Welding start" signal starts the welding process. The welding process re-
mains active while the "Welding start" signal is present.
Exception:
-
62
LOW (0) .. 0 - 2.5 V
HIGH (1) .. 18 - 30 V
The digital "Power source ready" output signal is absent
HIGH
