Screw the wire outlet nozzle on to the feed pipe
18
19
20
21
40
On the 4-roller drive of the cold-wire feed, swivel the tensioning device (4) to
a vertical position
On the 4-roller drive of the cold-wire feed, set the contact pressure with the
tensioning nuts (14) and (15).
IMPORTANT! Adjust the contact pressure so that the welding wire is not dis-
torted and the wire travels smoothly.
Close the left side of the cold-wire feed
Set the mains switch on the cold-wire feed to 0, and remove cable from
mains.
A detailed description of the procedure can be found in the manual for the
cold-wire feed.
Screw the wire outlet nozzle (17)
17
on to the feed pipe
(17)
