Feeding the welding wire into the Robacta KD Dri-
ve
Feeding the wel-
1
ding wire into the
Robacta KD Dri-
2
ve
(11)
Setting the feed rollers in the KD 7000, feeding in the welding wire
3
4
5
6
7
8
9
10
11
38
Set the mains switch on the cold-wire feed to 0, and disconnect the cable
from the mains
Open the left side of the cold-wire feed.
(7) (14)
(12)
( ) 8
On the 4-roller drive of the cold-wire feed, swivel forward the tensioning de-
vices (3) and (4)
On the 4-roller drive of the cold-wire feed, push the pressure levers (5) and
(6) up
On the 4-roller drive of the cold-wire feed, set the feed rollers (7) - (10) ac-
cording to the welding wire to be fed through
On the 4-roller drive of the cold-wire feed push the welding wire (11) via the
inlet pipe (12) about 50 mm (1,97 in.) into the inlet pipe of the TIG Robacta
KD Drive robot hosepack (13)
On the 4-roller drive of the cold-wire feed push the pressure levers (5) and
(6) down
On the 4-roller drive of the cold-wire feed swivel the tensioning device (3) in-
to a vertical position - Tensioning device (4) remains open
On the 4-roller drive of the cold-wire feed set the contact pressure to low
using the tensioning nut (14) (max. 2)
Line up the TIG Robacta KD Drive robot hosepack as straight as possible
On the cold-wire feed set the threading speed to slow (max. 4 m/min)
(3) (5)
(9) 1 ( ) 0
(6) (4) (15)
(13)
