Fitting the Robacta KD Drive

Fitting the cold-
1
wire feed
Remove sleeve from torch hosepack
1
Push support with drive unit on to torch ho-
sepack - if necessary use a screwdriver to open
up the support

Fitting the torch

1
Gas nozzle
Halve supplied tungsten electrode, assemble torch head
2
Support
Loosen screw on the support
2
Spacer
Cold-wire feed
Insert sleeve from torch hosepack in cold-wire
feed, push the cold-wire feed with spacer on to
the torch hosepack
Tungsten
electrode
31
