EN
This product is part of a personal fall arrest, work positioning, or rescue system. The user must follow the manufacturer's
instructions for each component of the system. These instructions must be provided to the user of this equipment. The user
must read and understand these instructions before using this equipment. Manufacturer's instructions must be followed for
proper use and maintenance of this equipment. Alterations or misuse of this product or failure to follow instructions may
result in serious injury or death. If this product is resold outside the original country of destination, the re-seller must provide
these instructions in the language of the country in which the product will be used.
IMPORTANT:
If you have questions on the use, care, or suitability of this equipment for your application, contact Capital
Safety.
IMPORTANT:
Before using this equipment, record the product identifi cation information from the ID label in the inspection
and maintenance log of this manual.
GLOSSARY REFERENCES
Numbered Glossary References on the front cover of this instruction reference the following items:
User Instructions.
1
Rebel™ Self Retracting Lifelines.
2
Model Numbers: (See Figure 1).
3
Standards.
4
DESCRIPTIONS:
Rebel SRLs are 6 ft (2.0 m) Self Retracting Lifelines, equipped with an in-line Load Indicator, which retract into
a Thermoplastic Housing. Rebel SRLs are available in several model confi gurations that allow attachment to an
anchorage point and single or dual mounting on a Full Body Harness or similar equipment (see Figure 1). The
Rebel SRL automatically locks at the onset of a fall to arrest the fall, but pays out and retracts lifeline during
normal movement by the attached user.
Figure 2 illustrates key components of Rebel SRLs:
A Swivel
E Web Lifeline
1.0 APPLICATIONS
1.1 PURPOSE: Capital Safety Self Retracting Lifelines (SRLs) are designed to be a component in a personal
fall arrest system (PFAS). Figure 1 illustrates SRLs covered by this instruction manual and their typical
applications. They may be used in most situations where a combination of worker mobility and fall protection
is required (i.e. inspection work, general construction, maintenance work, oil production, confi ned space
work, etc.).
1.2 STANDARDS: Your SRL conforms to the national standard(s) identifi ed on the front cover of these
instructions.
1.3 TRAINING: This equipment is intended to be used by persons trained in its correct application and use. It is
the responsibility of the user to assure they are familiar with these instructions and are trained in the correct
care and use of this equipment. Users must also be aware of the operating characteristics, application limits,
and the consequences of improper use.
2.0 LIMITATIONS & REQUIREMENTS
Always consider the following limitations and requirements when installing or using this equipment:
2.1 CAPACITY: SRLs are designed for use by one person with a combined weight (person, clothing, tools, etc.)
not exceeding 310 lbs (140 kg) and at least 75 lbs (34 kg).
At no time shall more than one person connect to a single SRL for fall arrest applications.
2.2 MAXIMUM ARREST FORCE AND MAXIMUM ARREST DISTANCE: SRLs documented in this instruction meet
the following Arrest Force maximums:
Weight of Worker
Average Arresting Force
Maximum Arresting Force
2.3 ANCHORAGE: Anchorage structure for the SRL must be capable of supporting loads up to 2,700 lbs (12 kN).
Anchor devices must conform to EN795.
WARNING:
The anchor point must be located at the same height or above the edge over which a fall might occur. Failure
to heed this warning may result in equipment malfunction, serious injury, or death.
B Swivel Eye C
F Load Indicator G
Up to 310 lbs (140 kg)
900 lbs (4.0 kN)
1,350 lbs (6.0 kN)
Number of body that performed CE test.
5
Number of body checking the manufacture of this PPE.
6
Read user instructions.
7
Carabiner (optional) D
Snap Hook
6
Housing
