OPERATION & INSTALLATION MANUAL FOR PC-RLH8/10
4 OPTIONAL FUNCTIONS
1) Open the lid of case by removing two screws so that the following functions are available.
PC-RLH8
Switch "COOL" Switch "HEAT"
2) Optional Setting for Dip Switch (SW3)
Operation Function
Slave-Remote Control Switch.
Setting for Simultaneous
Operation.
PC-RLH10
Switch "COOL"
Switch "HEAT"
Dip Switch
(SW3; Factory Supplied)
2) Optional Setting for Dip Switch (SW3)
Operation Function
Setting of Sub Receiver kit
Identifying of Indoor Units
Dip Switch
(SW3; Factory Supplied)
Rear Side of Indoor Unit
DIP Switch Setting (SW3)
ON
1 2 3 4
Hole for
Cable
Cover Prinetd Circuit Board
DIP Switch Setting (SW3)
ON
1 2 3 4
ON
1 2 3 4
7
Remove the screw
Cover
Remove two screws
and open the case
Case
