ANHANG B
Register Configuration F – Status Register
15 14 13 12
A4 A4 A3 A3
Relay Alarm Status flags (A1, A2, A3, A4)
Example:
A1 = 00=OK (relay de-energized)
A1 = 01=High (or Fault) (relay energized)
A1 = 10=Low (relay energized)
Pressure/Temperature Sensor Status (PS)
0=OK
1=Fault (or not available)
Register Configuration G – Liquid Selection
15 14 13 12
M2 M2 M2
Liquid Selection (LQ)
0 = n-Butane
1 = n-Propane
2 = n-Hexane
3 = Cumene
4 = Benzene
5 = Toluene
6 = 1-butane
7 = Cyclohexane
8 = Oct-3-ene
9 = Ethylbenzene
10 = Dimethylbenzene
11 = Ethane
12 = Methylcyclohexane
13 = Butylbenzene
14 = Prop-1-ene
15 = But-1-ene
16 = Methane
17 = 2-Methylbutane
18 = USER1
19 = USER2
20 = MIXING
44
11 10 9 8
A2 A2 A1 A1
11 10 9 8
M2 M2 M1 M1
Mixed Liquid 1 (M1)
0 = n-Butane
1 = n-Propane
2 = n-Hexane
3 = Cumene
4 = Benzene
5 = Toluene
6 = 1-butane
7 = Cyclohexane
8 = Oct-3-ene
9 = Ethylbenzene
10 = Dimethylbenzene
11 = Ethane
12 = Methylcyclohexane
13 = Butylbenzene
14 = Prop-1-ene
15 = But-1-ene
16 = Methane
17 = 2-Methylbutane
18 = USER1
19 = USER2
Promet I.S. Bedienungsanleitung
7 6 5 4
Dew point Sensor Status (DS)
0=OK
1=Fault (or not available)
7 6 5 4
M1 M1 M1 LQ
Mixed Liquid 1 (M2)
0 = n-Butane
1 = n-Propane
2 = n-Hexane
3 = Cumene
4 = Benzene
5 = Toluene
6 = 1-butane
7 = Cyclohexane
8 = Oct-3-ene
9 = Ethylbenzene
10 = Dimethylbenzene
11 = Ethane
12 = Methylcyclohexane
13 = Butylbenzene
14 = Prop-1-ene
15 = But-1-ene
16 = Methane
17 = 2-Methylbutane
18 = USER1
19 = USER2
97221 DE Ausgabe 6, November 2023
3 2 1 0
PS DS
3 2 1 0
LQ LQ LQ LQ
