ANHANG B
Reading values from register manually:
If value in register is greater than 32767: (value-65536)/x
If value in register is less than or equal to 32767: value/x
e.g. for type B3
(64997-65536)/100 = -5.39
201/100 = 2.01
Or Cast:
((float) ((signed short)value))/x;
Register Configuration C – System Configuration
15 14 13 12
PP MOD
Pressure Units (PU)
00 = Bar.G (def)
01 = Psi.G
10 = Mpag
11 = Spare
Main Unit
0 = Dp (O %)
2
1 = ppm (I) (O ppm)
V 2
2 = lbmmscf
3 = mg/m
3
4 = ppm (N)
V
Pressure Source (PR)
0 = Sensor
1 = Fixed User
Model (MOD)
0 = Promet
1 = Easidew Advanced
42
11 10 9 8
CA PR IT IT
Promet I.S. Bedienungsanleitung
7 6 5 4
TU PU PU
Temperature Unit (TU)
0 = C (def)
1 = F
Instrument Type (IT) – not used
00 = Promet IS
01 = Liquidew IS
10 = Pura
11 = O
2
ISO or IGT calculations (CA)
0=IGT
1=ISO
Pressure or ppm (I) secondary parameter
V
(PP) – Easidew Advanced only
0 = Pressure
1 = ppm (ideal)
V
97221 DE Ausgabe 6, November 2023
3 2 1 0
N/A MU MU MU
