chip depth can be found on the scale (6).
Operating the
thicknesser
Remove the mains plug before car-
rying out any adjustments.
Setting the cutting depth
When thicknessing, the chip removal is
adjusted via the crank handle (3).
A maximum of 2 mm of wood can
be planed off per pass. If you want
to remove more than 2 mm of wood, make
several passes.
1. Measure the current height of the work-
piece to be machined.
2. Using the crank handle (3), set the
desired height (�� current height minus
max. 2 mm). The set height can be
found on the scale (31).
3. Place the workpiece on the planing table
(23) and push the workpiece towards
the cutting roll using the push stick (18).
4. If the desired height has not yet been
reached, readjust the workpiece height
(max. 2 mm) and repeat the process un-
til you have reached the desired height.
Replacing and
J
aligning the blades
Cutting hazard! Do not hold
the blade by its cutting edges.
Two blades are installed in the blade shaft.
Always replace the blades in pairs. Do not
attempt to sharpen the blades!
Always change the planer blades
one after the other. In this way, you
can use the one that is still installed
to guide you during fitting.
Replacement blades are available
from our online shop (see "Spare
parts/Accessories").
Replacing the blades
1. Unscrew the four hexagon socket
screws (32).
2. Remove the guide (33).
3. Remove the planer blade (34) from the
blade shaft (36).
4. Insert a new planer blade, making sure
that the two adjusting screws (35) are
seated in the rectangular recesses in
the blade.
5. Put the guides (33) onto the blade.
6. Fasten the blade using the four hexa-
gon socket screws (32).
Aligning the blade
The blade may protrude over the blade
block by max. 1.1 mm. After alignment,
the blade must be level on the blade set-
ting block.
1. Place the blade setting block (17) on
the blade shaft.
2. Adjust the blade height by screwing/un-
screwing the two adjusting screws (35).
Cleaning and servicing
Remove the mains plug before car-
rying out any adjustments, mainte-
nance or repair work.
Have any work on the device
that is not described in this in-
struction manual performed by a
professional. Only use original parts.
Allow the device to cool off before
performing any maintenance or
cleaning. There is a danger of burns!
GB
MT
33
