Addi-Data APCI-7300-3 Referenzhandbuch Seite 3

APCI-7500-3: 37-pol. SUB-D-Stecker
37-pol. SUB-D-Stecker Pinbelegung
mit getauschten Modem Control
Signalen DCD und DSR.
APCI-7500-3: Rev. A-C
Pin-Nr.
1, 10, 24, 33
2, 11, 25, 34
3, 12, 26, 35
4, 13, 27, 36
5, 14, 28, 37
6, 15, 20, 29
APCI-7800-3: 78-pol. SUB-D-Stecker
78-pol. SUB-D-Stecker Pinbelegung
mit getauschten Modem Control
Signalen DCD und DSR.
APCI-7800-3: Rev. A-B
Pin-Nr.
1, 6, 11, 16, 62, 67, 72, 77
2, 7, 12, 17, 63, 68, 73, 78
3, 8, 13, 18, 40, 64, 69, 74
4, 9, 14, 20, 60, 65, 70, 75,
5, 10, 15, 19, 61, 66, 71, 76
21, 23, 26, 31, 36, 48, 53, 58
22, 27, 32, 37, 44, 49, 54, 59
23, 28, 33, 38, 41, 45, 50, 55
24, 29, 34, 39, 42, 46, 51, 56
www.addi-data.com
Standard 37-pol. SUB-D-Stecker Pinbe-
legung
APCI-7500-3: ab Rev. D
Signal
DSR
RXD
TXD
DTR
GND
DCD
Standard 78-pol. SUB-D-Stecker Pinbe-
legung
APCI-7800-3: ab Rev. C
Signal
RI 1, 6, 11, 16, 62, 67, 72, 77
DTR 2, 7, 12, 17, 63, 68, 73, 78
GND 3, 8, 13, 18, 40, 64, 69, 74
TXD 4, 9, 14, 20, 60, 65, 70, 75,
RXD 5, 10, 15, 19, 61, 66, 71, 76
DCD 21, 23, 26, 31, 36, 48, 53, 58
DSR 22, 27, 32, 37, 44, 49, 54, 59
CTS 23, 28, 33, 38, 41, 45, 50, 55
RTS 24, 29, 34, 39, 42, 46, 51, 56
Pin-Nr.
1, 10, 24, 33
2, 11, 25, 34
3, 12, 26, 35
4, 13, 27, 36
5, 14, 28, 37
6, 15, 20, 29
Pin-Nr.
Signal
DCD
RXD
TXD
DTR
GND
DSR
Signal
RI
DTR
GND
TXD
RXD
DSR
DCD
CTS
RTS
