You can test the torch-trigger functions by pressing the torch
trigger.
Display
A V
S t d - 0 -
S t d - 0 -
U - d - 0 -
U - d - 0 -
U - d - 0 -
U - d - 0 -

4. LEVEL 2 - CODE-LOCK

General points:
- The ex-factory code-lock setting is „not activated"
- Always keep a written note of any changes you make in the code
combination
- If three incorrect attempts are made to enter the code, all functions are
locked and „LOC" appears on the left-hand display
machine off and on, and enter the correct code.
Advantages of the code-lock:
- Only authorised personnel have access to the welding machine
- Anti-theft device, as the machie cannot be used unless the code is
entered

4.1 ENTERING THE CURRENT CODE

- If the code is activated, you must enter the current code before you can
make any changes to the code
Display
A V
C o d 3
C o d 2
C o d 1

4.2 ACTIVATION / DEACTIVATION OF CODE

- You can activate (turn on) and deactivate (turn off) the code by pressing
the torch trigger
Display
A V
C o d o f f
- If you have deactivated the code, the next two points („Entering the cycles", chapter 4.3, and „Entering the new code", chapter 4.4) will be bypassed
and you will be taken directly to chapter 4.5 „Saving the code".
Torch trigger of standard torch is pulled back
Torch trigger of standard torch is pushed forward
Torch trigger of up/down torch is pulled back
Torch trigger of up/down torch is pushed forward
UP button of up/down torch is pushed forward
DOWN button of up/down torch is pulled back
. Switch the
Entry of current code combination
The „hundreds" digit of the current code is entered using the
main-current dial I
H
The „tens" digit of the current code is entered using the main-
current dial I
H
The „units" digit of the current code is entered using the main-
current dial I
H
Activation / deactivation of code
The code can be (turned on) and deactivated (turned off) with
the torch trigger
To exit:
- Continue to next menu by pressing function button
Torch trigger recognition
To enter Level 2:
- Switch on the machine, pressing function button
- When „- - -", appears on the displays, keep pressing the function button
and press the torch trigger until „P 2" appears on the left-hand display
- Release function button
- The code is factory-set to „321", i.e. before you can change the code for
the first time, you must use the newly-set code combination.
- When dispatched from the factory, the code is deactivated
12
at the same time
Continue with
Function button
Function button
Function button
Continue with
Function button
