DEAR FRONIUS CUSTOMER
This brochure is intended to familiarise you with how to operate and
maintain your Setup-functions and Error-displays of the MAGIC WAVE
2600 FUZZY / MAGIC WAVE 2600 CEL resp. TRANSTIG 2600 / TRANSTIG
3000. You will find it well worthwhile to read through the manual carefully
and to follow all the instructions it contains. This will help you to avoid
operating errors - and the resultant malfunctions. Your machine will repay
you by giving you constant operational readiness for many years to come.
FRONIUS SCHWEISSMASCHINEN
VERTRIEB GMBH & CO KG
Warning! The machine may only be put into service by trained
personnel, and only in accordance with the technical directions.
Before you start using the machine, you must read the section
headed "Safety rules".
DATA SECURITY
The machine settings are stored in the power-source control unit (board
UTMS 1, n°: 4.070.501).
The set values are stored on an EEPROM.
It is the user's responsibility to back up data and change the memory
module in sufficient time.
When you exit the "FAC" menu (= factory settings), all the values are re-set
(apart from code settings).
CONTENTS
Dear Fronius Customer ............................................................................ 3
Safety rules ................................................................................................ 4
Controls ...................................................................................................... 6
1. Overview of Error outputs .................................................................... 7
2. Level 0 - Presettings .......................................................................... 8
2.1 Setting the TIG paramters ............................................................. 8
2.2 Setting the electrode parameters ................................................. 8
2.3 Basic settings ................................................................................. 9
3. Level 1 - Service ................................................................................. 9
3.1 Indication of versions ..................................................................... 9
3.2 Test programs ............................................................................... 10
3.2.1 Test of front board and controls ............................................... 10
3.2.2 Test of remote-control unit functions ....................................... 10
3.2.3 Test of various assemblies ....................................................... 11
3.2.4 Torch trigger test ....................................................................... 11
4. Level 2 - Code-lock .......................................................................... 12
4.1 Entering the current code ............................................................ 12
4.2 Activation / Deactivation of code ................................................ 12
4.3 Entering the n° of cycles ............................................................. 13
4.4 Entering the new code ................................................................. 13
4.5 Saving the new code .................................................................... 13
4.6 „Locking" of machine function ..................................................... 13
5. Level 3 - AC functions ...................................................................... 14
