Simons Voss Technologies PegaSys 2.1 Kurzanleitung Seite 3

PegaSys Authorisation reader 2.1 and
4.1 Display/keypad
6
1
2
Abbildungen/Images
Connections of authorisation reader 2.1 with display/
keypad
VCC (voltage for IO controller)
COM- (ground for IO controller)
COM+
+TX
-TX
+V
-V
PE (functional earthing)
Connection cable
to display module
6. Connections of authorisation
reader 2.1 with display/keypad
Cable to adapter board
Debug connection
DIP address switch
3 / 64
