PegaSys Authorisation reader 2.1 and
4.1 Display/keypad
6 Connections of authorisation
Display reader
Adapter
board in
reader
Matching IO
controller
(without DIP
switch)
7 Installation of authorisation
EN
reader 2.1 with display/keypad
1
2
3
reader 2.1 with display/keypad
1. If necessary, prepare the wall for installation (e.g.
drilling and/or dowelling).
2. Open the reader unit housing with the installation
tool.
4
3. Disconnect the connection cable between the
reader module and the wall frame.
5
4. Screw the wall frame to the wall.
6
5. Connect the cables to the pre-assembled adapter
board.
7
6. If necessary, set the address for the RS485 bus on
the reader module.
8
6. Connections of authorisation
reader 2.1 with display/keypad
