ESPAÑOL
ADVERTENCIA:
PARA PREVENIR INCENDIOS O RIESGO DE DESCARGA, NO EXPONGA EL
APARATO A LA LLUVIA O LA HUMEDAD. NO RETIRE LA CUBIERTA. PILOTOS
SOLDADOS A LA UNIDAD. NO CONTIENE PIEZAS SUSTITUIBLES POR EL
USUARIO. LAS TAREAS DE SERVICIO DEBERÁN SER REALIZADAS POR
PERSONAL DE SERVICIO CUALIFICADO.
PRECAUCIÓN
RIESGO DE DESCARGA
ELÉCTRICA. NO ABRIR
El símbolo del rayo en un PRECAUCIÓN: PARA REDUCIR EL
triángulo equilátero está
RIESGO DE DESCARGA ELÉCTRICA,
destinado a alertar al usuario
NO RETIRE LA CUBIERTA (O PARTE
de la presencia de "voltaje
POSTERIOR). NO CONTIENE –
peligroso" no aislado dentro
del alojamiento del producto, PIEZAS SUSTITUIBLES POR EL
el cual podría poseer la
USUARIO. LAS TAREAS DE
magnitud suficiente como
SERVICIO DEBERÁN SER
para constituir un riesgo de
REALIZADAS POR PERSONAL DE
descarga eléctrica para las
personas.
SERVICIO CUALIFICADO.
"La ventilación no debe obstruirse".
"No exponga la unidad a salpicaduras o goteos así como también no coloque objetos llenos con líquidos,
como vasijas, sobre el aparato".
Especificaciones
FRECUENCIA
Puerto USB 2.0
RANURA DE TARJETA SD
FUENTE DE ALIMENTACIÓN
ANTENA
CONSUMO DE ENERGÍA
TAMAÑO DE ALTAVOZ
MANDO A DISTANCIA
Sustitución de la pila de litio requerida
*EL DISEÑO Y LAS ESPECIFICACIONES SE ENCUENTRAN SUJETOS A CAMBIOS SIN PREVIO AVISO.
El signo de exclamación
en un triángulo equilátero
está destinado a alertar
al usuario de la presencia
de importantes
instrucciones de uso y
mantenimiento (servicio)
en el folleto que
acompaña al aparato.
: FM 88 - 108 MHz
AM 530 - 1600 KHz
: Alta velocidad 512 MB - 4 GB
(Compatible con FAT16, FAT32)
: 512 MB - 4 GB
: CA 230 V ~ 50 Hz
: Antena externa para FM
Barra de ferrita integrada para AM
: 18 W
: 2 x 3" x 5" 8 ohmios tipo dinámico
: Está instalada una pila de celda -
: 1 x 3 V CR2025
45
ENGLISH
TROUBLESHOOTING
There is no power
Make sure the unit is plugged in correctly.
Make sure the unit is switched on by the ON/OFF POWER SWITCH.
There is no sound
Check to make sure the power is turned on.
Check the volume level by turning the On/Off Power Switch/Volume Control.
Check the Line In Switch on the back of the unit to make sure it is in the OFF position.
Check you did not leave any Headphones plugged in – this will cut all sound form the speakers.
Make sure the INT./EXT. switch on the back of the radio is switched to INT. (Unless you are using external
speakers, in which case it should be on EXT.)
The Turntable will not work
Make sure the unit is set to Phono mode by sliding the Function switch.
Try moving the Tone arm to the right until you hear a click - the turntable should start rotating.
Make sure the Turntable Drive Belt has not come off. To replace the belt, see separate Instructions and diagrams.
The Tone Arm will not move
The black tie-wrap has not been removed from the Tone Arm.
The Tone Arm hold down clip has not been released.
Make sure you lift the Tone Arm with the Cue Lever and then move it manually over the edge of the record –
then lower it with the Cue Lever. Caution: Do not force it down onto the record without using the Cue Lever.
The Tone Arm slides across the Record
Make sure the protective needle cover is removed.
Make sure the Stylus has not been damaged – replace if necessary.
Your record may be one of the newer types with micro grooves and may need a different stylus to play
successfully. Any of the older style records should not have this problem.
Turntable – the sound is low when playing a record
Try removing and refitting the stylus.
Turn up the volume.
I have recorded a Record but it does not display any Folder/Artist/Title or Song Information
Vinyl records have no digital information, so no MP3 song information will be stored on the USB device or
card. However, if required, MP3 tracks can be transferred to, viewed and named on a computer.
I have recorded a CD but it does not display any Folder/Artist/Title or Song Information
If this information was not already on the original Disc, this will not show on the recorded disc either.
The CD does not play
Check to make sure the CD is inserted correctly (label side facing up).
Make sure the Function switch is set to CD and a CD is in the tray.
Make sure the CD is not blank.
Check that the surface of the CD is clean. See separate Instructions on CD Care.
USB /SD Card - no music is playing when PLAY/PAUSE is pressed
Make sure there are MP3 music files stored on the USB Device/Flash Drive / SD Card.
Check the USB Device/Flash Drive / SD Card is not larger than 4GB as the limit of this unit is up to 4GB max.
Try resetting the USB by powering off.
Check if the files on the device/card are perhaps in WMA format. This unit does not play WMA format, only
MP3 format.
Not all makes of USB device/SD Card are compatible with this unit – this is not a malfunction of the unit.
Cannot Record Music on the USB /SD Card
Make sure the USB/SD Card is not full.
Make sure the lock switch on the SD card is in the unlocked position.
It may be the device/card is not compatible or of the correct size (up to 4GB max.) – not all available USB/SD
devices are guaranteed to work with this unit due to the way they are manufactured.
The recorded MP3 Music does not have the same sound quality as the original CD
The sound quality of an MP3 disc varies from that of a pre-recorded Audio Compact Disc, due to the quality
and method of recording and the difference in format.
The Remote is not working
Replace the battery. See Specifications for type of battery required.
Remove any obstacles in the path of the Infra Red Remote and the Remote Sensor next to the LCD Display,
so the remote signal has a straight path to it.
Cassette will not work
Make sure the FUNCTION SWITCH is set to phono.
Make sour the cassette tape is not empty.
Make sour the cassette tape is not at the end.
The unit keeps shutting itself down
This unit has a POWER SAVING FEATURE: to comply with new regulations, if the unit is not operated or there
is no signal output for 15 minutes, it will automatically turn itself off.
Turn the MAIN POWER switch to OFF and then to ON again to re-activate the unit.
