2. If you are installing an indoor dome camera, skip this step and go on to
step 3 now.
If you are installing an outdoor dome camera:
Decide whether you will insert the network cable and the secondary
cable through the cable pass-through hole in the side of the camera
base or in the back of the camera base. (The secondary cable is the
cable that can be used to carry alternate camera power, digital I/O, RS-
485, and audio signals to the camera.)
Use the round plug and the plug insertion tool included in the dome
camera kit to plug the hole that you will not be using as shown below.
Note that the plug should have an O-ring on it as shown in the drawing.
O-ring
Basler IP Fixed Dome Cameras
Side Hole
Plug
Insertion
Tool
Plug
Installation Guide
Back Hole
