Installation Guide
2. Insert the cable(s) through the cap nut as shown below.
Cap Nut
3. Place the two cables in the grooves of the split grommet as shown below.
Make sure that the ends of the cables extend 15 cm (6 inches) past the
grommet as shown below.
Note: If you are using only one cable, use the split grommet with only one
groove.
Split
Grommet
12
Secondary
Cable
Ethernet
Cable
Split
Grommet
