Installation Guide
Isolated I/O Circuit
+5
VDC
1 kΩ
(Set as an output)
Isolated Alternate
Camera Power Circuit
(Outdoor dome cameras only)
Isolated
RS-485
Circuit
Fig. 4: I/O, Alternate Power, and RS-485 Schematic
40
Camera
DC Out
I/O-1
+5
VDC
1 kΩ
I/O-0
(Set as an input)
I/O Gnd
(isolated)
Heater Off
VDC
Camera
Power Gnd
(isolated)
RS-485 Gnd
(isolated)
Switch
(Jumper Heater
Off to Gnd to
disable heater)
B-
A+
Basler IP Fixed Dome Cameras
AW00101404000
+24
VDC
Max
Relay
+12 to +24
VDC
RS-485 B-
RS-485 A+
RS-485 Gnd
Device
