Installation Guide
To adjust the focus:
Depending on whether you are using a dome camera model with or without
autofocus functionality, there are two different ways to adjust the focus:
manual focus adjustment and autofocus adjustment.
For more information about the specific camera models with autofocus
functionality, refer to the basic specification tables in Section 9 on page 42.
Manual focus adjustment
When you are using a camera model without autofocus functionality, adjust the
focus manually.
1. Loosen the focus puller by turning it counter-clockwise as shown in the
following drawing.
2. Adjust the focus by moving the puller left and right.
3. When complete, tighten the focus puller.
Zoom
Puller
26
AW00101404000
Focus
Puller
Basler IP Fixed Dome Cameras
